BaroCRYPT integration Guide(PostgreSQL)

API guide for the BaroCRYPT solution for lightweight and fastest cryptographic algorithms(PostgreSQL)



Index

1. PostgreSQL encryption/decryption module
1.1 pgcrypto module
1.2 Pre-confirmation items
1.3 Encryption/Decryption function
1.4 Create encryption/decryption function
1.5 Confirm creation of encryption/decryption functions
1.6 Encryption/decryption function test

2. About BaroCRYPT





1. PostgreSQL encryption/decryption module



1.1 pgcrypto module



The pgcrypto module provides cryptographic functions for PostgreSQL.



This module is considered a trusted module. That is, a user other than the super user who has the CREATE privilege on the current database can install it.



The raw encryption function of the pgcrypto module is as follows.

-convert_to/convert_from: convert/restore string

-encode/decode: hexadecimal encoding/decoding

-encrypt/decrypt: encrypt/decrypt



For encryption, convert to utf8, encrypt using the 'aes' algorithm as an encryption key, and then encode the value in hexadecimal (hex).



Ex) encode(encrypt(convert_to('name005', 'utf8'), 'ENC_KEY', 'aes'), 'hex')



ENC_KEY should be replaced with the actual encryption key to be used, and utf8, aes, and hex are fixed values.



Decryption is the reverse of encryption. After decoding the hexadecimal value, the encryption is released, and the value is converted back to utf8.



Ex) convert_from(decrypt(decode(mem_name,'hex'),'ENC_KEY','aes'),'utf8')



ENC_KEY should be replaced with the actual decryption key to be used, and utf8, aes, and hex are fixed values



1.2 Pre-confirmation items



1) Check currently installable modules



[root@baropam ~]# su - postgres Verification code:   [postgres@baropam ~]$ psql barocryptdb psql (10.17) Type "help" for help.     postgres=# select * from pg_catalog.pg_available_extensions;



If not, proceed as follows.



2) Find the settings file



[Module name].control is the configuration file for installing the module.



$ find / -name pgcrypto.control -print



If you cannot find it, you must install postgresql-contrib using the following command.



$ yum install postgresql-contrib -y



3) Compiling and installing extension modules



$ cd /root/postgresql-1x.x/contrib/pgcrypto $ ./configure $ make -f makefile $ make install



If you go through the above process, the following files will be copied.



/usr/local/pgsql/share/contrib/pgcrypto.sql /usr/local/pgsql/share/contrib/uninstall_pgcrypto.sql /usr/local/pgsql/lib/pgcrypto.so



4) Install expansion module



[Important] Connect to the relevant DB administrator to install.

Check who the owner of the DB is using the \l command.

Basically, if no option values are specified, public schema functions are created.



postgres=# create extension pgcrypto;



5) Check currently installed modules



postgres=# select * from pg_catalog.pg_extension;



6) Function test



postgres=# select encode(encrypt(convert_to('barocrypt', 'utf-8'), 'utf-8', 'AES'), 'hex');





1.3 Encryption/Decryption function



1) TO_ENCRYPTS function



- NAME

  TO_ENCRYPTS



- SYNOPSIS

  char    TO_ENCRYPTS(data char)

varchar TO_ENCRYPTS(data varchar)

txt     TO_ENCRYPTS(data text)



- DESCRIPTION

A function that encrypts data.

  data: data to encrypt



- RETURN VALUES

 return encrypted data



2) TO_DECRYPTS function



- NAME

  TO_DECRYPTS



- SYNOPSIS

char    TO_DECRYPTS(data char)

varchar TO_DECRYPTS(data varchar)

txt     TO_DECRYPTS(data text)



- DESCRIPTION

 A function to decrypt data.

  data: data to decrypt



- RETURN VALUES

 Return the decrypted data





1.4 Create encryption/decryption function



1) Install extension modules



postgres=# CREATE EXTENSION pgcrypto; CREATE EXTENSION postgres=#



2) Create encryption/decryption functions



postgres=# CREATE OR REPLACE FUNCTION TO_ENCRYPTS(data char) postgres-# RETURNS char AS postgres-# $$ BEGIN postgres$#     RETURN encode(encrypt(convert_to(data, 'utf8'), 'Encryption KEY', 'aes'), 'hex'); postgres$# END; $$ postgres-# LANGUAGE PLPGSQL; CREATE FUNCTION postgres=# CREATE OR REPLACE FUNCTION TO_DECRYPTS(data char) postgres-# RETURNS char AS postgres-# $$ BEGIN postgres$#     RETURN convert_from(decrypt(decode(data, 'hex'), 'Decryption KEY', 'aes'), 'utf8'); postgres$# END; $$ postgres-# LANGUAGE PLPGSQL; CREATE FUNCTION postgres=# CREATE OR REPLACE FUNCTION TO_ENCRYPTS(data varchar) postgres-# RETURNS varchar AS postgres-# $$ BEGIN postgres$#     RETURN encode(encrypt(convert_to(data, 'utf8'), 'Encryption KEY', 'aes'), 'hex'); postgres$# END; $$ postgres-# LANGUAGE PLPGSQL; CREATE FUNCTION postgres=# CREATE OR REPLACE FUNCTION TO_DECRYPTS(data varchar) postgres-# RETURNS varchar AS postgres-# $$ BEGIN postgres$#     RETURN convert_from(decrypt(decode(data, 'hex'), 'Decryption KEY', 'aes'), 'utf8'); postgres$# END; $$ postgres-# LANGUAGE PLPGSQL; CREATE FUNCTION postgres=# CREATE OR REPLACE FUNCTION TO_ENCRYPTS(data text) postgres-# RETURNS text AS postgres-# $$ BEGIN postgres$#     RETURN encode(encrypt(convert_to(data, 'utf8'), 'Encryption KEY', 'aes'), 'hex'); postgres$# END; $$ postgres-# LANGUAGE PLPGSQL; CREATE FUNCTION postgres=# CREATE OR REPLACE FUNCTION TO_DECRYPTS(data text) postgres-# RETURNS text AS postgres-# $$ BEGIN postgres$#     RETURN convert_from(decrypt(decode(data, 'hex'), 'Decryption KEY', 'aes'), 'utf8'); postgres$# END; $$ postgres-# LANGUAGE PLPGSQL; CREATE FUNCTION postgres=#





1.5 Confirm creation of encryption/decryption functions



postgres=# \df                                         List of functions  Schema |         Name          | Result data type  |        Argument data types         |  Type  --------+-----------------------+-------------------+------------------------------------+--------  public | armor                 | text              | bytea                              | normal  public | armor                 | text              | bytea, text[], text[]              | normal  public | crypt                 | text              | text, text                         | normal  public | dearmor               | bytea             | text                               | normal  public | decrypt               | bytea             | bytea, bytea, text                 | normal  public | decrypt_iv            | bytea             | bytea, bytea, bytea, text          | normal  public | digest                | bytea             | bytea, text                        | normal  public | digest                | bytea             | text, text                         | normal  public | encrypt               | bytea             | bytea, bytea, text                 | normal  public | encrypt_iv            | bytea             | bytea, bytea, bytea, text          | normal  public | gen_random_bytes      | bytea             | integer                            | normal  public | gen_random_uuid       | uuid              |                                    | normal  public | gen_salt              | text              | text                               | normal  public | gen_salt              | text              | text, integer                      | normal  public | hmac                  | bytea             | bytea, bytea, text                 | normal  public | hmac                  | bytea             | text, text, text                   | normal  public | pgp_armor_headers     | SETOF record      | text, OUT key text, OUT value text | normal  public | pgp_key_id            | text              | bytea                              | normal  public | pgp_pub_decrypt       | text              | bytea, bytea                       | normal  public | pgp_pub_decrypt       | text              | bytea, bytea, text                 | normal  public | pgp_pub_decrypt       | text              | bytea, bytea, text, text           | normal  public | pgp_pub_decrypt_bytea | bytea             | bytea, bytea                       | normal  public | pgp_pub_decrypt_bytea | bytea             | bytea, bytea, text                 | normal  public | pgp_pub_decrypt_bytea | bytea             | bytea, bytea, text, text           | normal  public | pgp_pub_encrypt       | bytea             | text, bytea                        | normal  public | pgp_pub_encrypt       | bytea             | text, bytea, text                  | normal  public | pgp_pub_encrypt_bytea | bytea             | bytea, bytea                       | normal  public | pgp_pub_encrypt_bytea | bytea             | bytea, bytea, text                 | normal  public | pgp_sym_decrypt       | text              | bytea, text                        | normal  public | pgp_sym_decrypt       | text              | bytea, text, text                  | normal  public | pgp_sym_decrypt_bytea | bytea             | bytea, text                        | normal  public | pgp_sym_decrypt_bytea | bytea             | bytea, text, text                  | normal  public | pgp_sym_encrypt       | bytea             | text, text                         | normal  public | pgp_sym_encrypt       | bytea             | text, text, text                   | normal  public | pgp_sym_encrypt_bytea | bytea             | bytea, text                        | normal  public | pgp_sym_encrypt_bytea | bytea             | bytea, text, text                  | normal  public | to_decrypts           | character         | data character                     | normal  public | to_decrypts           | character varying | data character varying             | normal  public | to_decrypts           | text              | data text                          | normal  public | to_encrypts           | character         | data character                     | normal  public | to_encrypts           | character varying | data character varying             | normal  public | to_encrypts           | text              | data text                          | normal (42 rows) postgres=#





1.6 Encryption/decryption function test



1) Encryption function (TO_ENCRYPTS)



postgres=# SELECT TO_ENCRYPTS('qwer1234');            to_encrypts            ----------------------------------  2b9a5a43f720621f1c791f8882a75195 (1 row) postgres=#



2) Decryption function (TO_DECRYPTS)



postgres=# SELECT TO_DECRYPTS('2b9a5a43f720621f1c791f8882a75195');  to_decrypts -------------  qwer1234 (1 row) postgres=#
